BODOR N
| Model | Round Tube Range(mm) | Max. Tube Length (mm) | Max. Tube Weight (kg) | Laser Power (kW) | Max. Chuck Rotation Speed (r/min) |
|---|---|---|---|---|---|
| N2 | Round Tube: Ø8–Ø230 mm Square Tube: □8–□230 mm Rectangular Tube: Side Length ≤230 mm Angle Steel: 2#–14# Channel Steel: 5#–14# | 6500 | 300 | 3–6 | 110 |
| N3 | Round Tube: Ø25–Ø360 mm Square Tube: □25–□350 mm Rectangular Tube: Side Length ≤360 mm Angle Steel: 2#–22# Channel Steel: 5#–22# | 6500 / 9200 / 12500 | 1200 | 6–12 | 60 |
| N5 | Round Tube: Ø25–Ø356 mm Square Tube: □25–□356 mm Rectangular Tube: Side Length ≤356 mm Angle Steel: 2#–22# Channel Steel: 5#–22# | 9200 / 12500 / 15200 | 2000 | 6–20 | 40 |
